| 新锐 Part No. | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth Max. (V) | RDS(ON) (mΩ) typ. at VGS= | ID (A) | |||
| 10V | 4.5V | 2.5V | 1.8V | |||||||||
| XR2305 | SOT23 | Single | P | -20 | ±12 | -1.0 | -------- | 57 | 75 | -------- | -5 | |
| XR2305A | SOT23 | Single | P | -20 | ±12 | -1.0 | -------- | -------- | -5 | |||
| XR3415 | SOT23 | Single | P | -15 | ±10 | -1.2 | -------- | 28 | 34 | -------- | -5 | |
| XR20P07 | SOT23 | Single | P | -20 | ±12 | -1.0 | -------- | 22 | 27 | -------- | -5.8 | |
| XR90-12 | SOT23 | Single | P | -18 | ±12 | -1.0 | -------- | 75 | 107 | -------- | -2.5 | |
| XR80B | SOT23 | Single | P | -18 | ±12 | -1.0 | -------- | 70 | 105 | -------- | -2.5 | |
| XR2305A | SOT23 | Single | P | -20 | ±12 | -1.0 | -------- | 32 | 45 | -------- | -3.6 | |
| XR30P05 | SOT23 | Single | P | -30 | ±20 | -2.5 | 44 | 55 | -------- | -------- | -5 | |
| XR3415A | SOT23 | Single | P | -20 | ±12 | -1.0 | -------- | 35 | 45 | -------- | -4.5 | |
| XR3415 | ESD | SOT23 | Single | P | -20 | ±10 | -1.0 | -------- | 34 | 50 | -------- | -4.1 |
| XR35B | SOT23 | Single | P | -12 | ±12 | -1.2 | -------- | 48 | 70 | -------- | -4 | |
| XR2333 | SOT23 | Single | P | -18 | ±12 | -1.0 | -------- | 20 | 25 | -------- | -6 | |
