系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | RDS(ON) (mΩ) typ. at VGS= | ID (A) | ||
10V | 4.5V | 2.5V | ||||||||||
Trench | XR2305B | - | SOT23 | Single | P | -20 | ±12 | -1 | -------- | 30 | 35 | -4.1 |
XR2311 | - | SOT23 | Single | P | -19 | ±12 | -1 | -------- | 25 | 30 | -5 | |
XR2311L | - | SOT23 | Single | P | -19 | ±12 | -1 | -------- | 24 | 29 | -5 | |
XR2313L | - | SOT23-3L | Single | P | -19 | ±12 | -1 | -------- | 17 | 24 | -7 | |
XR2317L | - | SOT23-3L | Single | P | -18 | ±12 | -0.65 | -------- | 18 | 25 | -7 | |
XR1216M | - | DFN2020-6L | Single | p | -15 | ±12 | -1.2 | -------- | 11 | 14 | -16 | |
XR1212M | - | DFN2020-6L | Single | p | -20 | ±12 | -1.2 | -------- | 13 | 19 | -12 | |
XR25P01M | - | DFN2020-6L | Single | p | -15 | ±12 | -1.2 | -------- | 6.5 | 9.5 | -25 | |
