系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | RDS(ON) (mΩ) typ. at VGS= | ID (A) | ||
10V | 4.5V | 2.5V | ||||||||||
N+P | XR4616 | - | SOP8 | Complementary | N | 30 | ±20 | 2.5 | 10 | 16 | -------- | 9 |
- | P | -30 | ±20 | -2.5 | 23 | 30 | -------- | -9 | ||||
XR3030 | - | TO252-4L | Complementary | N | 30 | ±20 | 2.5 | 9 | 14 | -------- | 30 | |
- | P | -30 | ±20 | -2.5 | 18 | 26 | -------- | -30 | ||||
XR30G30D | - | PDFN3333-8L | Complementary | N | 30 | ±20 | 2.5 | 9.5 | 16 | -------- | 20 | |
- | P | -30 | ±20 | -2.5 | 21 | 31 | -------- | -20 | ||||
XR30G30F | - | PDFN5060-8L | Complementary | N | 30 | ±20 | 2.5 | 9.5 | 16 | -------- | 30 | |
- | P | -30 | ±20 | -2.5 | 21 | 31 | -------- | -20 | ||||
XR50G30F | - | PDFN5060-8L | Complementary | N | 30 | ±20 | 2.5 | 7.5 | 10 | -------- | 45 | |
- | P | -30 | ±20 | -2.5 | 8.7 | 17 | -------- | -45 | ||||
XR4020F | - | PDFN5060-8L | Complementary | N | 40 | ±20 | -2.5 | 17 | 25 | -------- | 20 | |
- | P | -40 | ±20 | -2.5 | 33 | 45 | -------- | -20 | ||||
XR4030F | - | PDFN5060-8L | Complementary | N | 40 | ±20 | 2.5 | 13 | 17 | -------- | 25 | |
- | P | -40 | ±20 | -2.5 | 25 | 32 | -------- | -25 | ||||
