系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | RDS(ON) (mΩ) typ. at VGS= | ID (A) | ||
10V | 4.5V | 2.5V | ||||||||||
Trench | XR80N03C | - | TO252-3L | Single | N | 30 | ±20 | 1.6 | 4.2 | 6.3 | -------- | 80 |
XR100N03 | - | TO252-3L | Single | N | 30 | ±20 | 1.5 | 3.5 | 5.5 | -------- | 100 | |
XR120N03 | - | TO252-3L | Single | N | 30 | ±20 | 1.7 | 3 | 4 | -------- | 120 | |
XR150N03 | - | TO252-3L | Single | N | 30 | ±20 | 1.6 | 1.5 | 3.2 | -------- | 150 | |
XR100N04 | - | TO252-3L | Single | N | 40 | ±20 | 1.5 | 3.8 | 5.7 | -------- | 100 | |
XR120N04 | - | TO252-3L | Single | N | 40 | ±20 | 1.5 | 2.2 | 3.3 | -------- | 120 | |
