系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | RDS(ON) (mΩ) typ. at VGS= | ID (A) | ||
10V | 4.5V | 2.5V | ||||||||||
N+P | XR4614 | - | SOP8 | Complementary | N | 40 | ±20 | 2.5 | 17 | 25 | -------- | 8.5 |
- | P | -40 | ±20 | -2.5 | 39 | 58 | -------- | -7.5 | ||||
XR10G04S | - | SOP8 | Complementary | N | 40 | ±20 | 2.5 | 17 | 25 | -------- | 10 | |
- | P | -40 | ±20 | -2.5 | 32 | 43 | -------- | -10 | ||||
XR3030 | - | TO252-4L | Complementary | N | 30 | ±20 | 2.5 | 9 | 14 | -------- | 30 | |
- | P | -30 | ±20 | -2.5 | 18 | 26 | -------- | -30 | ||||
