| Series | Ordring No | ESD | Package Type |
Configura Tion |
MOSFET Type |
VDS(V) | VGS(V) | Vth Typ.(V) | RDS(ON) (mΩ) typ. at VGS= | ID(A) | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10V | 4.5V | ID(A) | ||||||||||
| 60V N+P | XR4559A | SOP8 | Complementary | N | 60 | ±20 | 2.5 | 30 | 36 | - | 6 | |
| 60V N+P | XR10G06S | SOP8 | Complementary | P | -60 | ±20 | -2.5 | 51 | 65 | - | -10 | |
| 60V N+P | XR10G06S | SOP8 | Complementary | N | 60 | ±20 | 2.5 | 32 | 39 | - | 10 | |
| 60V N+P | XR60G25F | PDFN5*6 | Complementary | P | -60 | ±20 | -2.5 | 35 | 42 | - | -25 | |
| 60V N+P | XR60G25F | PDFN5*6 | Complementary | N | 60 | ±20 | 2.5 | 25 | 31 | - | 25 | |
| 60V N+P | XR60G20F | PDFN5*6 | Complementary | P | -60 | ±20 | -2.5 | 42 | 55 | - | -20 | |
| 60V N+P | XR60G20F | PDFN5*6 | Complementary | N | 60 | ±20 | 2.5 | 25 | 31 | - | 25 | |
| 60V N+P | XR4559A | SOP8 | Complementary | P | -60 | ±20 | -2.5 | 70 | 100 | - | -5 | |
| 60V N+P | XR4612 | SOP8 | Complementary | N | 60 | ±20 | 2.5 | 60 | 70 | - | 5 | |
| 60V N+P | XR4612 | SOP8 | Complementary | P | -60 | ±20 | -2.5 | 100 | 115 | - | -4 | |
| 60V N+P | XR6012 | TO252-4L | Complementary | N | 60 | ±20 | 2.5 | 40 | 48 | - | 12 | |
| 60V N+P | XR6012 | TO252-4L | Complementary | P | -60 | ±20 | -2.5 | 75 | 85 | - | -12 | |
| 60V N+P | XR6020 | TO252-4L | Complementary | N | 60 | ±20 | 2.5 | 30 | 35 | - | 20 | |
| 60V N+P | XR6020 | TO252-4L | Complementary | P | -60 | ±20 | -2.5 | 70 | 85 | - | -15 | |
| 60V N+P | XR6030 | TO252-4L | Complementary | N | 60 | ±20 | 2.5 | 25 | 31 | - | 30 | |
| 60V N+P | XR6030 | TO252-4L | Complementary | P | -60 | ±20 | -2.5 | 35 | 42 | - | -30 | |
| 40V N+P | XR4020F | PDFN5*6 | Complementary | N | 40 | ±20 | -2.5 | 17 | 25 | - | 20 | |
| 40V N+P | XR4020F | PDFN5*6 | Complementary | P | -40 | ±20 | -2.5 | 33 | 45 | - | -20 | |
| 40V N+P | XR4030F | PDFN5*6 | Complementary | N | 40 | ±20 | 2.5 | 13 | 17 | - | 25 | |
| 40V N+P | XR4030F | PDFN5*6 | Complementary | P | -40 | ±20 | -2.5 | 25 | 32 | - | -25 | |
