系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | ID (A) | |||
10V | 4.5V | 2.5V | ||||||||||
SJ | XR65R500 | - | TO252-3L | Singel | N | 650 | ±30 | 3 | 500 | -------- | -------- | 8 |
XR65R380 | - | TO252-3L | Singel | N | 650 | ±30 | 3 | 380 | -------- | -------- | 11 | |
XR65R25FTG2 | - | TO220F | Singel | N | 650 | ±30 | 3 | 250 | -------- | -------- | 13 | |
XR65R380FT | - | TO220F | Singel | N | 650 | ±30 | 3 | 380 | -------- | -------- | 11 | |
系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | ID (A) | |||
10V | 4.5V | 2.5V | ||||||||||
SGT | XRS75N10F | - | PDFN5060-8L | Single | N | 100 | ±20 | 1.8 | 6.5 | 7.9 | -------- | 75 |
XRS100N10LF | - | PDFN5060-8L | Single | N | 100 | ±20 | 1.8 | 4.4 | 6.6 | -------- | 100 | |
XRS100N10HF | - | PDFN5060-8L | Single | N | 100 | ±20 | 3 | 4.5 | 6.6 | -------- | 100 | |
XRS130N10HF | - | PDFN5060-8L | Single | N | 100 | ±20 | 3 | 3.6 | -------- | -------- | 130 | |
XRS80N12F | - | PDFN5060-8L | Single | N | 120 | ±20 | 1.8 | 7.5 | 9.5 | -------- | 80 | |
XRS100N12HF | - | PDFN5060-8L | Single | N | 120 | ±20 | 3 | 6 | -------- | -------- | 100 | |
系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | ID (A) | |||
10V | 4.5V | 2.5V | ||||||||||
Trench | XR2320L | - | SOT23-3L | Single | N | 20 | ±12 | 0.7 | -------- | 11 | 16 | 8 |
XR3410L | - | SOT23-3L | Single | N | 30 | ±20 | 1.5 | 12 | 16 | -------- | 7 | |
XR30N03D | - | PDFN3333-8L | Single | N | 30 | ±20 | 1.5 | 8 | 11 | -------- | 30 | |
XR50N03D | - | PDFN3333-8L | Single | N | 30 | ±20 | 1.5 | 7 | 10 | -------- | 50 | |
SGT | XRS60N03D | - | PDFN3333-8L | Single | N | 30 | ±20 | 1.8 | 5 | 6.9 | -------- | 62 |
Trench | XR50P03D | - | PDFN3333-8L | Single | P | -30 | ±20 | -1.5 | 8.7 | 15 | -------- | -50 |
XR60P03D | - | PDFN3333-8L | Single | P | -30 | ±20 | -1.5 | 7.5 | 10.5 | -------- | -60 | |
SGT | XRS60N04D | - | PDFN3333-8L | Single | N | 40 | ±20 | 1.8 | 6.9 | 10 | -------- | 60 |
XRS60N04F | - | PDFN5060-8L | Single | N | 40 | ±20 | 1.8 | 6.8 | 9.8 | -------- | 60 | |
