系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | RDS(ON) (mΩ) typ. at VGS= | ID (A) | ||
10V | 4.5V | 2.5V | ||||||||||
Trench | XR4406A | - | SOP8 | Single | N | 30 | ±20 | 1.5 | 8.5 | 13 | -------- | 13 |
XR4406B | - | SOP8 | Single | N | 30 | ±12 | 1 | 14 | 20 | -------- | 8 | |
XR4407B | - | SOP8 | Single | P | -30 | ±20 | -1.5 | 14.5 | 19 | -------- | -10 | |
XR4407A | - | SOP8 | Single | P | -30 | ±20 | -1.5 | 9.5 | 17 | -------- | -12 | |
XR3350M | Y | DFN3030-8L | Dual | N | 20 | ±10 | 0.7 | -------- | 3.2 | 4.2 | 50 | |
XR3330M | Y | DFN3030-8L | Dual | N | 20 | ±10 | 0.7 | -------- | 5.8 | 6.8 | 30 | |
XR3325M | Y | DFN2030-6L | Dual | N | 20 | ±10 | 0.7 | -------- | 5.8 | 6.8 | 25 | |
系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | RDS(ON) (mΩ) typ. at VGS= | ID (A) | ||
10V | 4.5V | 2.5V | ||||||||||
Trench | XR100N03 | - | TO252-3L | Single | N | 30 | ±20 | 1.5 | 3.5 | 5.5 | -------- | 100 |
XR150N03 | - | TO252-3L | Single | N | 30 | ±20 | 1.6 | 1.5 | 3.2 | -------- | 150 | |
SGT | XRS320N04TL | - | TOLL-8L | Single | N | 40 | ±20 | 1.8 | 0.75 | 1.4 | -------- | 320 |
XRS200N06LTL | - | TOLL-8L | Single | N | 60 | ±20 | 1.8 | 2 | -------- | -------- | 200 | |
XRS400N06TL | - | TOLL-8L | Single | N | 60 | ±20 | 3 | 1.25 | -------- | -------- | 200 | |
XRS320N08TL | - | TOLL | Single | N | 80 | ±20 | 3 | 1.6 | -------- | -------- | 320 | |
XRS400N08TL | - | TOLL | Single | N | 80 | ±20 | 3 | 1.2 | -------- | -------- | 400 | |
XRS130N85G | - | TO263 | Single | N | 80 | ±20 | 3 | 4.5 | -------- | -------- | 130 | |
XRS300N10TL | - | TOLL | Single | N | 100 | ±20 | 3 | 2.3 | -------- | -------- | 300 | |
XRS350N10TL | - | TOLL | Single | N | 100 | ±20 | 3 | 1.4 | -------- | -------- | 350 | |
XRS120N10G | - | TO263 | Single | N | 100 | ±20 | 3 | 4.5 | -------- | -------- | 120 | |
XRS150N10G | - | TO263 | Single | N | 100 | ±20 | 3 | 3.4 | -------- | -------- | 150 | |
XRS260N10G | - | TO263 | Single | N | 100 | ±20 | 3 | 2.4 | -------- | -------- | 260 | |
系列 | Ordering No 下单型号 | ESD | Package Type | Configuration | MOSFET Type | VDS (V) | VGS (V) | Vth typ. (V) | RDS(ON) (mΩ) typ. at VGS= | ID (A) | ||
10V | 4.5V | 2.5V | ||||||||||
SGT | XRS80P06G | - | TO263 | Single | P | -60 | ±20 | -1.8 | 9 | 12 | -------- | -80 |
XRS110P06G | - | TO263 | Single | P | -60 | ±20 | -2.4 | 5.5 | -------- | -------- | -110 | |
